HDMI Extender Kit 4K@60Hz 60M
- Type: HDMI Extender Kit
- Function: Extends Ultra HD HDMI video and audio signals over a single CAT5e/CAT6/CAT7 Ethernet cable
- Maximum Distance: Up to 60 meters (200 feet)
- Resolution Support: 4K @ 60Hz with full 4:4:4 color sampling
Designed for conference rooms, home theaters, digital signage, control rooms, and professional AV installations.
Key Features
Ultra HD 4K@60Hz Support
- Supports resolutions up to 3840 × 2160 @ 60Hz
- Full 18Gbps HDMI bandwidth
- Supports YUV 4:4:4 color format
- Compatible with HDR and Deep Color technology
- Delivers sharp and high-quality video transmission
Long-Distance HDMI Transmission
- Extends HDMI signals up to 60 meters over a single CAT5e/CAT6/CAT7 cable
- Supports longer transmission distances at lower resolutions such as 1080p or 4K@30Hz
- Stable and reliable signal transmission
HDMI Loop-Out Port
- HDMI output on the transmitter (TX) unit for local display monitoring
- Allows simultaneous local and remote video output
Bi-Directional IR Control
- Includes IR transmitter and receiver cables
- Enables remote control of the source device from the remote display location
- Supports original remote control functionality
HDCP 2.2 Compliance
- Supports HDCP 2.2 and HDCP 1.4
- Compatible with protected 4K content from streaming devices and media players
EDID Management
- Automatic EDID detection and configuration
- Ensures optimal compatibility between connected devices
- Simplifies setup without manual configuration
Power over Cable (PoC)
- Only one power adapter required
- Power is transmitted between TX and RX units through the Ethernet cable
- Reduces cable clutter and simplifies installation
Specifications
Video
- HDMI Version: HDMI 2.0
- HDCP Support: HDCP 2.2 / 1.4
- Maximum Resolution: 3840 × 2160 @ 60Hz
- Color Format: YUV 4:4:4
- HDR Support: Yes
- Video Bandwidth: 18Gbps
Transmission
- Transmission Media: Single CAT5e / CAT6 / CAT7 Cable
- Maximum Distance: Up to 60M (200ft)
Audio
- Supports HDMI embedded audio
- Compatible with high-definition audio formats
Features
- HDMI loop-out support
- IR remote extension support
- EDID management
- Power over Cable (PoC)
- Plug & Play installation
