Motion Detection & Smart Analytics
-
Motion Detection 2.0 (AI-based)
-
Human and vehicle classification
-
Dramatically reduces false alarms (leaves, lights, shadows, etc.)
-
Enabled by default on all analog channels
-
-
Smart Search
-
Quick search by object type or event type
-
Video & Audio
IP Video Input
-
1 channel (expandable up to 5 channels)
-
Up to 1080p resolution
-
Supports H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
-
4 channels
-
BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron
Supported Analog Formats
-
HDTVI: 1080p25/30, 720p25/30
-
AHD: 1080p25/30, 720p25/30
-
HDCVI: 1080p25/30, 720p25/30
-
CVBS: Supported
Video Output
-
HDMI Output
-
1920×1080 @60Hz
-
1280×1024 @60Hz
-
1280×720 @60Hz
-
-
VGA Output
-
Same resolutions as HDMI
-
-
HDMI & VGA simultaneous output
Audio
-
Audio Input
-
1-ch RCA (2.0 Vp-p, 1 kΩ)
-
4-ch via coaxial cable
-
-
Audio Output
-
1-ch RCA (Linear, 1 kΩ)
-
-
Two-way audio (uses first audio input)
-
Synchronous playback: 4 channels
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
Recording & Encoding
Video Compression
-
H.265 Pro+ / H.265 Pro / H.265
-
H.264+ / H.264
Encoding Resolution
-
1080p stream access:
-
1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF
-
-
720p stream access:
-
720p / WD1 / 4CIF / VGA / CIF
-
-
SD stream access:
-
WD1 / 4CIF / VGA / CIF
-
Frame Rate
-
Main Stream
-
Up to 25 fps (PAL) / 30 fps (NTSC) depending on resolution
-
-
Sub-stream
-
4CIF @15 fps
-
CIF/QVGA @25 fps (PAL) / 30 fps (NTSC)
-
-
Video Bitrate: 32 Kbps – 4 Mbps
-
Stream Type: Video or Video & Audio
Network
-
Total Incoming Bandwidth: 64 Mbps
-
Network Protocols:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS -
Remote Connections: Up to 32
-
Network Interface:
1 × RJ45 10/100 Mbps self-adaptive Ethernet
Storage & Interfaces
-
SATA: 1 × SATA port
-
Max HDD Capacity: Up to 4 TB
-
USB: 2 × USB 2.0 (rear panel)
-
Alarm I/O: Not supported
Power & Environment
-
Power Supply: 12 VDC, 1.5 A
-
Power Consumption: ≤ 16 W (without HDD)
-
Operating Temperature: -10 °C to 55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% – 90%
Physical
-
Dimensions:
200 × 200 × 48 mm (7.9 × 7.9 × 1.9 in) -
Weight:
≤ 0.8 kg (without HDD)
