Motion Detection 2.0
-
Deep learning–based motion detection enabled by default on all analog channels
-
Human and vehicle classification
-
Significantly reduces false alarms caused by environmental factors such as leaves and lighting changes
-
Quick search by object type or event type
Video & Audio
IP Video Input
-
2 channels (expandable up to 10 channels)
-
Maximum resolution: Up to 5 MP
-
Supports H.265+ / H.265 / H.264+ / H.264 IP cameras
Analog Video Input
-
8 channels
-
BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron
Supported Analog Formats
-
HDTVI: 1080p @25/30 fps, 720p @25/30 fps
-
AHD: 1080p @25/30 fps, 720p @25/30 fps
-
HDCVI: 1080p @25/30 fps, 720p @25/30 fps
-
CVBS: Supported
Video Output
-
HDMI Output
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
VGA Output
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
Output Mode: HDMI and VGA simultaneous output
Audio
-
Audio Input
-
1-ch RCA (2.0 Vp-p, 1 kΩ)
-
8-ch via coaxial cable
-
-
Audio Output: 1-ch RCA (Linear, 1 kΩ)
-
Two-Way Audio: Uses the first audio input
-
Synchronous Playback: 8 channels
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
Recording & Encoding
Video Compression
-
H.265 Pro+ / H.265 Pro / H.265
-
H.264+ / H.264
Encoding Resolution
-
1080p stream access:
1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF -
720p stream access:
720p / WD1 / 4CIF / VGA / CIF -
Standard Definition:
WD1 / 4CIF / VGA / CIF
Frame Rate
Main Stream
-
1080p: up to 15 fps
-
720p: up to 15 fps
-
SD: up to 25 fps (PAL) / 30 fps (NTSC)
Sub-Stream
-
1080p / 720p: CIF / QVGA @15 fps
-
SD: CIF / QVGA @25 fps (PAL) / 30 fps (NTSC)
-
Video Bitrate: 32 Kbps – 4 Mbps
-
Stream Type: Video or Video & Audio
Network
-
Total Bandwidth: 72 Mbps
-
Remote Connections: Up to 64
-
Protocols:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS -
Network Interface:
1 × RJ45 10/100 Mbps self-adaptive Ethernet
Storage & Interfaces
-
SATA: 1 × SATA interface
-
Maximum HDD Capacity: Up to 4 TB
-
USB: Rear panel: 2 × USB 2.0
-
Alarm I/O: Not supported
Power & Environment
-
Power Supply: 12 VDC, 1.5 A
-
Power Consumption: ≤ 17 W (without HDD)
-
Operating Temperature: −10 °C to 55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% – 90%
Physical
-
Dimensions (W × D × H):
263 × 227 × 48 mm (10.4 × 8.9 × 1.9 in) -
Weight: ≤ 1 kg (without HDD)
