Motion Detection 2.0
-
Deep learning–based motion detection enabled by default on all analog channels
-
Human and vehicle classification
-
Significantly reduces false alarms caused by leaves, lighting changes, and other irrelevant motion
-
Quick search by object type or event type
Video & Audio
IP Video Input
-
2 channels (expandable up to 18 channels)
-
Maximum resolution: Up to 5 MP
-
Supports H.265+ / H.265 / H.264+ / H.264 IP cameras
Analog Video Input
-
16 channels
-
BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron
Supported Analog Formats
-
HDTVI: 1080p @25/30 fps, 720p @25/30 fps
-
AHD: 1080p @25/30 fps, 720p @25/30 fps
-
HDCVI: 1080p @25/30 fps, 720p @25/30 fps
-
CVBS: PAL / NTSC
Video Output
-
HDMI Output
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
VGA Output
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
Output Mode: HDMI and VGA simultaneous output
Audio
-
Audio Input
-
1-ch RCA (2.0 Vp-p, 1 kΩ)
-
16-ch via coaxial cable
-
-
Audio Output: 1-ch RCA (Linear, 1 kΩ)
-
Two-Way Audio: 1-ch (uses first audio input)
-
Synchronous Playback: 16 channels
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
Recording & Encoding
Video Compression
-
H.265 Pro+ / H.265 Pro / H.265
-
H.264+ / H.264
Encoding Resolution
-
1080p stream access:
1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF -
720p stream access:
720p / WD1 / 4CIF / VGA / CIF -
Standard Definition:
WD1 / 4CIF / VGA / CIF
Frame Rate
Main Stream
-
1080p: up to 15 fps
-
720p: up to 15 fps
-
SD: up to 25 fps (PAL) / 30 fps (NTSC)
Sub-Stream
-
1080p / 720p: CIF / QVGA @15 fps
-
SD: CIF / QVGA @25 fps (PAL) / 30 fps (NTSC)
-
Video Bitrate: 32 Kbps – 4 Mbps
-
Dual Stream: Supported
-
Stream Type: Video or Video & Audio
Network
-
Total Bandwidth: 96 Mbps
-
Remote Connections: Up to 128
-
Protocols:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS, ONVIF -
Network Interface:
1 × RJ45 10/100 Mbps self-adaptive Ethernet
Storage & Interfaces
-
SATA: 1 × SATA interface
-
Maximum HDD Capacity: Up to 10 TB
-
USB: 2 × USB 2.0
Power & Environment
-
Power Supply: 12 VDC, 1.6 A
-
Power Consumption: ≤ 10 W (without HDD)
-
Operating Temperature: −10 °C to 55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% – 90%
Physical
-
Dimensions (W × D × H):
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 in) -
Weight: ≤ 1.1 kg (without HDD)
