Motion Detection & Smart Analysis
-
Motion Detection 2.0
-
Deep learning–based analysis enabled by default on all analog channels
-
Accurate human and vehicle classification
-
Greatly reduces false alarms caused by leaves, lighting changes, and other non-relevant motion
-
-
Smart Search
-
Quick search by object type or event type
-
Video & Audio
IP Video Input
-
1 channel (expandable up to 5 channels)
-
Up to 1080p resolution
-
Supports H.265+ / H.265 / H.264+ / H.264 IP cameras
Analog Video Input
-
4 channels
-
BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron
Supported Analog Formats
-
HDTVI: 1080p25/30, 720p25/30
-
AHD: 1080p25/30, 720p25/30
-
HDCVI: 1080p25/30, 720p25/30
-
CVBS: Supported
Video Output
-
HDMI Output:
1920×1080 @60Hz, 1280×1024 @60Hz, 1280×720 @60Hz -
VGA Output:
1920×1080 @60Hz, 1280×1024 @60Hz, 1280×720 @60Hz -
Output Mode: HDMI and VGA simultaneous output
Audio
-
Audio Input
-
1-ch RCA (2.0 Vp-p, 1 kΩ)
-
4-ch via coaxial cable
-
-
Audio Output
-
1-ch RCA (Linear, 1 kΩ)
-
-
Two-Way Audio: Uses first audio input
-
Synchronous Playback: 4 channels
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
Recording & Encoding
Video Compression
-
H.265 Pro+ / H.265 Pro / H.265
-
H.264+ / H.264
Encoding Resolution
-
1080p stream access:
1080p Lite, 720p Lite, WD1, 4CIF, VGA, CIF -
720p stream access:
720p, WD1, 4CIF, VGA, CIF -
SD stream access:
WD1, 4CIF, VGA, CIF
Frame Rate
Main Stream
-
Up to 25 fps (PAL) / 30 fps (NTSC) depending on resolution
Sub-Stream
-
4CIF @15 fps
-
CIF/QVGA @25 fps (PAL) / 30 fps (NTSC)
-
Video Bitrate: 32 Kbps – 4 Mbps
-
Stream Type: Video or Video & Audio
Network
-
Total Bandwidth: 64 Mbps
-
Protocols:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS -
Remote Connections: Up to 32
-
Network Interface:
1 × RJ45 10/100 Mbps self-adaptive Ethernet
Storage & Interfaces
-
SATA: 1 × SATA interface
-
Maximum HDD Capacity: Up to 4 TB
-
USB: 2 × USB 2.0 (rear panel)
-
Alarm I/O: Not supported
Power & Environment
-
Power Supply: 12 VDC, 1.5 A
-
Power Consumption: ≤ 16 W (without HDD)
-
Operating Temperature: −10 °C to 55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% to 90%
Physical
-
Dimensions (W × D × H):
200 × 200 × 48 mm (7.9 × 7.9 × 1.9 in) -
Weight:
≤ 0.8 kg (without HDD)
