Motion Detection 2.0
-
Deep learning–based motion detection enabled by default on all analog channels
-
Accurate human and vehicle classification
-
Significantly reduces false alarms caused by leaves, lighting changes, and other environmental motion
-
Quick search by object type or event type
Perimeter Protection
-
Line Crossing Detection and Intrusion Detection
-
Supports up to 4 channels
Facial Detection
-
Face detection and capture
-
Face picture detection and face image search
Video & Audio
IP Video Input
-
2 channels (expandable up to 18 channels)
-
Enhanced IP Mode ON:
-
8 channels (expandable up to 24 channels)
-
Up to 4 Mbps per channel
-
-
Maximum resolution: Up to 6 MP
-
Supports H.265+ / H.265 / H.264+ / H.264 IP cameras
Analog Video Input
-
16 channels
-
BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron
-
Incoming bandwidth: 96 Mbps
Supported Analog Formats
-
HDTVI
-
3K (2960 × 1665) @20 fps
-
5 MP (2560 × 1944) @20 fps
-
4 MP (2560 × 1440) @25/30 fps
-
1080p @25/30 fps
-
720p @25/30 fps
-
-
AHD
-
5 MP (2592 × 1944) @20 fps
-
4 MP (2560 × 1440) @25/30 fps
-
1080p @25/30 fps
-
720p @25/30 fps
-
-
HDCVI
-
5 MP (2880 × 1620) @25 fps
-
5 MP (2592 × 1944) @20 fps
-
4 MP (2560 × 1440) @25/30 fps
-
1080p @25/30 fps
-
720p @25/30 fps
-
-
CVBS: PAL / NTSC
Video Output
-
HDMI Output
-
4K (3840 × 2160) @30 Hz
-
2K (2560 × 1440) @60 Hz
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
VGA Output
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
Audio
-
Audio Input
-
1-ch RCA (2.0 Vp-p, 1 kΩ)
-
16-ch via coaxial cable
-
-
Audio Output: 1-ch RCA (Linear, 1 kΩ)
-
Two-Way Audio: 1-ch (uses first audio input)
-
Synchronous Playback: 16 channels
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
Recording & Encoding
Video Compression
-
H.265 Pro+ / H.265 Pro / H.265
-
H.264+ / H.264
Encoding Resolution
1080p Lite Disabled
-
3K Lite / 5 MP Lite / 4 MP Lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF
1080p Lite Enabled
-
3K Lite / 5 MP Lite / 4 MP Lite / 1080p Lite / 720p Lite / VGA / WD1 / 4CIF / CIF
Frame Rate
Main Stream (1080p Lite Disabled)
-
3K / 5 MP: up to 12 fps (Lite)
-
4 MP: up to 15 fps (Lite), 1080p Lite up to 20 fps
-
720p and below: up to 20 fps
-
PAL / NTSC: up to 25 / 30 fps depending on resolution
Main Stream (1080p Lite Enabled)
-
3K Lite / 5 MP Lite: 12 fps
-
4 MP Lite: 15 fps
-
1080p Lite and below: 25 fps (PAL) / 30 fps (NTSC)
Sub-Stream
-
WD1 / 4CIF @12 fps
-
CIF @25 fps (PAL) / 30 fps (NTSC)
-
Video Bitrate: 32 Kbps – 6 Mbps
-
Dual Stream: Supported
-
Stream Type: Video or Video & Audio
Network
-
Total Bandwidth: 128 Mbps
-
Remote Connections: Up to 128
-
Protocols:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF -
Network Interface:
1 × RJ45 10/100/1000 Mbps self-adaptive Ethernet
Storage & Interfaces
-
SATA: 1 × SATA interface
-
Maximum HDD Capacity: Up to 10 TB
-
USB: 2 × USB 2.0 (rear panel)
-
Alarm I/O: Not supported
Power & Environment
-
Power Supply: 12 VDC, 2 A
-
Power Consumption: ≤ 24 W
-
Operating Temperature: −10 °C to +55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% – 90%
Physical
-
Dimensions (W × D × H):
285 × 210 × 48 mm (11.2 × 8.3 × 1.9 in) -
Weight: ≤ 1 kg (without HDD)
