Facial Recognition
Face Picture Library
-
Supports up to 16 face picture libraries
-
Face libraries are backed up on HDD and flash memory
-
HDD damage will not cause face library data loss
Face Picture Comparison
-
4-channel face picture comparison alarm
-
Based on HD analog camera capture
Perimeter Protection
-
Human / Vehicle analysis
-
Supports up to 8 channels (advanced model)
Facial Detection
-
Facial detection and capture
-
Face picture detection and face picture search
-
4-channel face picture capture
Video & Audio
IP Video Input
-
8 channels (expandable up to 16 channels)
-
Each channel supports up to 8 MP
Analog Video Input
-
8 channels
-
BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron
Supported Analog Formats
HDTVI
-
8 MP (3840 × 2160) @12/15 fps
-
3K (2960 × 1665) @20/25 fps
-
3K (3328 × 1504) @20 fps
-
2K (2304 × 1296) @20 fps
-
5 MP (2560 × 1944) @20 fps
-
4 MP (2560 × 1440) @25/30 fps
-
1080p @25/30 fps
-
720p @25/30 fps
AHD
-
5 MP (2560 × 1944) @20 fps
-
4 MP (2560 × 1440) @25/30 fps
-
1080p @25/30 fps
-
720p @25/30 fps
HDCVI
-
8 MP (3840 × 2160) @12/15 fps
-
3K (2880 × 1620) @20/25 fps
-
5 MP (2592 × 1944) @20 fps
-
4 MP (2560 × 1440) @25/30 fps
-
1080p @25/30 fps
-
720p @25/30 fps
CVBS
-
PAL / NTSC
Video Output
-
HDMI Output
-
4K (3840 × 2160) @30 Hz
-
2K (2560 × 1440) @60 Hz
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
VGA Output
-
1920 × 1080 @60 Hz
-
1280 × 1024 @60 Hz
-
1280 × 720 @60 Hz
-
-
Output Mode: HDMI and VGA simultaneous output
-
CVBS Output
-
1-ch BNC (1.0 Vp-p, 75 Ω)
-
Resolution:
-
PAL: 704 × 576
-
NTSC: 704 × 480
-
-
Audio
-
Audio Input
-
1-ch RCA (up to 8 channels optional)
-
8-ch via coaxial cable
-
-
Audio Output: 1-ch RCA (Linear, 1 kΩ)
-
Two-Way Audio: 1-ch RCA (uses the first audio input)
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
Recording & Encoding
Video Compression
-
H.265 Pro+ / H.265 Pro / H.265
-
H.264+ / H.264
Encoding Resolution
-
8 MP / 5 MP / 3K / 4 MP / 3 MP
-
1080p / 720p / WD1 / 4CIF / VGA / CIF
Frame Rate
Main Stream
-
8 MP @8 fps
-
3K @12 fps
-
5 MP @12 fps
-
4 MP @15 fps
-
8 MP Lite @15 fps
-
3 MP @18 fps
-
1080p / 720p / WD1 / 4CIF / VGA / CIF
-
25 fps (PAL) / 30 fps (NTSC)
-
Sub-Stream
-
WD1 / 4CIF / CIF
-
25 fps (PAL) / 30 fps (NTSC)
-
-
Video Bitrate: 32 Kbps – 10 Mbps
-
Dual-Stream: Supports main stream or sub-stream
-
Stream Type: Video or Video & Audio
Decoding
-
Decoding Capability:
Up to 24-channel 1080p @30 fps
Network
-
Total Bandwidth: 256 Mbps
-
Remote Connections: Up to 64
-
Protocols:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP -
Network Interface:
1 × RJ45 10/100/1000 Mbps self-adaptive Ethernet
Storage & Interfaces
-
SATA: 1 × SATA interface
-
Maximum HDD Capacity: Up to 12 TB
-
Serial Interface: RS-485 (half-duplex)
-
USB
-
Front panel: 1 × USB 2.0
-
Rear panel: 2 × USB 3.0
-
-
Alarm I/O: Not supported (optional)
Power & Environment
-
Power Supply: 12 VDC, 2 A
-
Power Consumption: ≤ 24 W
-
Operating Temperature: −10 °C to +55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% – 90%
Physical
-
Dimensions (W × D × H):
319 × 240 × 48 mm (12.6 × 9.4 × 1.9 in) -
Weight: ≤ 2 kg (4.4 lb)
