Facial Recognition
-
Face Picture Library: Supports up to 16 libraries
-
Data Backup: HDD damage will not cause data loss, as libraries are backed up on HDD and flash
-
Face Picture Comparison: 4-ch face comparison alarm (HD analog camera)
Motion Detection 2.0
Human / Vehicle Analysis
-
Deep learning-based motion detection enabled by default on all analog channels
-
Classifies human vs vehicle, reducing false alarms caused by leaves, lights, and other objects
-
Supports quick search by object type or event type
Perimeter Protection
-
Human / Vehicle analysis
-
Supports up to 16 channels (advanced model)
Facial Detection
-
Facial detection and capture
-
Face picture detection and search
-
Supports 4-ch face picture capture
Video & Audio
IP Video Input
-
8 channels (expandable up to 40 channels)
-
Maximum resolution: 6 MP per channel
Analog Video Input
-
32 channels
-
BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported
Supported Analog Formats
HDTVI
-
8 MP (3840 × 2160) @15 / 12 fps
-
3K (2960 × 1665 / 3328 × 1504) @20 / 25 fps
-
5 MP (2560 × 1944) @12 / 20 fps
-
4 MP (2560 × 1440) @25 / 30 fps
-
1080p @25 / 30 fps
-
720p @25 / 30 fps
AHD
-
5 MP (2560 × 1944) @20 fps
-
4 MP (2560 × 1440) @25 / 30 fps
-
1080p / 720p @25 / 30 fps
HDCVI
-
3K (2880 × 1620) @25 fps
-
5 MP (2592 × 1944) @20 fps
-
4 MP (2560 × 1440) @25 / 30 fps
-
1080p / 720p @25 / 30 fps
CVBS: PAL / NTSC
Video Output
-
HDMI: 1-ch, up to 4K (3840 × 2160) @30 Hz, 2K (2560 × 1440) @60 Hz, 1080p @60 Hz, 1280 × 1024 / 1280 × 720 @60 Hz
-
VGA: 1-ch, up to 1920 × 1080 @60 Hz
-
HDMI & VGA output simultaneous
-
CVBS Output: 1-ch, PAL: 704 × 576 / NTSC: 704 × 480
Audio
-
Audio Input: 1-ch RCA (up to 16-ch optional), 32-ch via coaxial cable
-
Audio Output: 1-ch RCA (Linear, 1 kΩ)
-
Two-Way Audio: 1-ch RCA (uses first audio input)
-
Audio Compression: G.711u
-
Audio Bitrate: 64 Kbps
-
Synchronous Playback: 16-ch
Recording & Encoding
Video Compression: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Encoding Resolution
-
8 MP / 5 MP / 3K / 4 MP / 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF
Frame Rate (Main Stream)
-
8 MP @8 fps
-
3K @12 fps
-
5 MP @12 fps
-
4 MP @15 fps
-
8 MP Lite @15 fps
-
3 MP @18 fps
-
1080p / 720p / WD1 / 4CIF / VGA / CIF @25 fps (P) / 30 fps (N)
Sub-Stream: WD1 / 4CIF / CIF @25 fps (P) / 30 fps (N)
Video Bitrate: 32 Kbps – 10 Mbps
Dual-stream: Supported
Stream Type: Video, or Video & Audio
Decoding
-
Up to 24-ch 1080p @30 fps
Network
-
Total Bandwidth: 256 Mbps
-
Remote Connections: 128
-
Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
-
Network Interface: 1 × RJ45 10/100/1000 Mbps, self-adaptive
Storage & Interfaces
-
SATA: 2 interfaces, up to 12 TB each
-
RS-485 Serial Interface: Half-duplex
-
USB: Front 1 × USB 2.0, Rear 2 × USB 3.0
-
Alarm I/O: Optional
Power & Environment
-
Power Supply: 12 VDC, 5 A
-
Power Consumption: ≤ 60 W
-
Operating Temperature: −10 °C to +55 °C (14 °F to 131 °F)
-
Operating Humidity: 10% – 90%
Physical
-
Dimensions (W × D × H): 384 × 313 × 52 mm (15.1 × 12.3 × 2.0 in)
-
Weight: ≤ 2.1 kg (4.6 lb)
